SN06R12-502-M

Euchner
Availability:

1 in stock


  • Plunger spacing 12 mm
  • Upright housing, small flange
  • Degree of protection IP67 according to IEC 60529

409,00

Mechanical values and environment

Design Upright
Housing material
Housing Die-cast aluminum, anodized
Weight
Net 0,65 kg
Ambient temperature -5 … 80 °C
Degree of protection IP67
Mechanical life 30 x 106
Contact material Silver alloy, gold flashed
Switching principle Snap-action switching contact
Plunger spacing 12 mm
Installation orientation Any
Number of switching elements 6
Number of NC contacts 6
Number of NO contacts 6
Connection
2 x M20 x 1.5
Approach speed 0,01 … 80 m/min
Actuating element
Plain bearing Roller plunger
Actuating force min.20 N

Electrical connection ratings

Thermal rated current Ith 8 A
Utilization category acc. to EN 60947-5-1
AC-15 6A 230V
DC-13 6A 24V
AC-12 8 A, 250 V
Short circuit protection according to IEC 60269-1 8A gG
Rated insulation voltage Ui 250 V
Rated impulse withstand voltage Uimp 2,5 kV
Switching current
Min. at DC 12V min.10 mA
Connection cross-section 0,34 … 1,5 mm²
SKU: SN06R12-502-M Categories: , , ,
